Steam Generator
For years we have used steam to hydrate every foeder that leaves our shop. We have found no better way to clean a tank or keep it hydrated; however, the size and cost of industrial steam/boiler systems kept them out of reach of most of our customers. We teamed up with a leading American manufacturer to make a small, relatively inexpensive unit that suits the needs of Foeder Crafters and our clients.
FEATURES:
Stainless steel tank and water level probes provide years of
trouble-free operationRemovable heating elements provide easy and economical service
Simple on/off controls
Small size allows unit to be moved easily
ETL listed for USA and Canada
Tested to IEC standards
One-year commercial warranty
ELECTRICAL INFORMATION:
8-foot 220v locking L6-30P power adapter installed
30A dedicated circuit required
Can be hard wired in the field for 208-240v 1/3 phase power
PLUMBING INFORMATION:
Water inlet: 3/8” NPT
Steam outlet: 1½” tri-clamp adapter
Pressure relief: ¾” NPT
Drain outlet: ¾” NPT
INSTALLATION:
Install in dry, well ventilated area.
Install generator level hung on a wall.
Provide adequate access for service.
Run cold (preferably conditioned) water line with shut off valve.
Run steam line as short as possible. Slope pipe/hose to avoid creating condensation build up. Do not create traps or pipe obstructions.
Run ¾” pressure relief and drain lines in accordance with codes.
DIMENSIONS AND WEIGHT:
16½” x 15” x 6¼”
35 lbs.
